Edelbrock 5090 - Cylinder Heads, Chrysler 383-440, E-street, 75cc, Flat Tappet (Pair)

The Edelbrock #5090 E-Street cylinder heads are designed for use with 1961-1979 Chrysler 361-440 c.i.d. Wedge engine applications. The Edelbrock E-Street cylinder heads offer American made quality and affordable performance. E-Street cylinder heads feature as-cast ports and are designed for entry-level street performance applications operating in the idle-to-5500 rpm range. The modern combustion chamber designs improve the combustion process and larger than stock intake and exhaust ports move more air through your engine for improve efficiency.

  • Entry level street performance upgrade
  • A356 Aluminum
  • Sold as a pair
  • Edelbrock quality and performance
  • Affordable price
  • Made in U.S.A.
  • Engine swaps
DETAILS
Camshaft Type:
Hydraulic Flat Tappet
Car/Engine:
Chrysler Big Block
Chamber Volume:
75cc
Engine Notes:
383-440 cui
Exhaust Port Location:
Standard
HP Range:
400-550
Max. Lift:
0.600''
Port Volume Intake / Exh:
210cc / 70cc
Serie:
E-Street
Valve Sizes Intake / Exh:
2.14'' / 1.81''
Valve Spring Diameter:
1.55''
Available downloads:
Download instructions

0 of 0 reviews

Average rating of 0 out of 5 stars

Leave a review!

Share your experiences with other customers.


  • EQUIPPED WITH SPRINGS FOR USE IN HYDRAULIC FLAT TAPPET CAMSHAFT APPLICATIONS
  • Deck thickness: 5/8",
  • Pushrod diameter: 3/8"
  • Vacuum advance distributor may not clear cylinder head.
  • The 75cc combustion chamber allows this cylinder head to be used with stock pistons, retaining the 9.5:1 compression
  • The modern combustion chamber design also improves the combustion process and the larger than stock intake and exhaust ports move more air through your engine. These features improve the engine's efficiency, resulting in more horsepower and torque
  • These cylinder heads are sold in pairs

Edelbrock 5090 - Cylinder Heads, Chrysler 383-440, E-street, 75cc, Flat Tappet (Pair)

The Edelbrock #5090 E-Street cylinder heads are designed for use with 1961-1979 Chrysler 361-440 c.i.d. Wedge engine applications. The Edelbrock E-Street cylinder heads offer American made quality and affordable performance. E-Street cylinder heads feature as-cast ports and are designed for entry-level street performance applications operating in the idle-to-5500 rpm range. The modern combustion chamber designs improve the combustion process and larger than stock intake and exhaust ports move more air through your engine for improve efficiency.

  • Entry level street performance upgrade
  • A356 Aluminum
  • Sold as a pair
  • Edelbrock quality and performance
  • Affordable price
  • Made in U.S.A.
  • Engine swaps
DETAILS
Camshaft Type:
Hydraulic Flat Tappet
Car/Engine:
Chrysler Big Block
Chamber Volume:
75cc
Engine Notes:
383-440 cui
Exhaust Port Location:
Standard
HP Range:
400-550
Max. Lift:
0.600''
Port Volume Intake / Exh:
210cc / 70cc
Serie:
E-Street
Valve Sizes Intake / Exh:
2.14'' / 1.81''
Valve Spring Diameter:
1.55''

Available downloads:
Download instructions

0 of 0 reviews

Average rating of 0 out of 5 stars

Leave a review!

Share your experiences with other customers.


  • EQUIPPED WITH SPRINGS FOR USE IN HYDRAULIC FLAT TAPPET CAMSHAFT APPLICATIONS
  • Deck thickness: 5/8",
  • Pushrod diameter: 3/8"
  • Vacuum advance distributor may not clear cylinder head.
  • The 75cc combustion chamber allows this cylinder head to be used with stock pistons, retaining the 9.5:1 compression
  • The modern combustion chamber design also improves the combustion process and the larger than stock intake and exhaust ports move more air through your engine. These features improve the engine's efficiency, resulting in more horsepower and torque
  • These cylinder heads are sold in pairs
