Edelbrock 79949 - Cylinder Head, Chevrolet LS1/LS2 Gen III&IV, E-CNC 215, 65cc, Hydraulic Roller

The Edelbrock 79949 E-CNC Small Block Chevy GEN 3 & 4 LS cylinder head are designed for 1997 & later GEN 3 & 4 LS1/LS2 Chevy engines including 4.8L, 5.3L, 5.7L & 6.0L. The E-CNC Cylinder Head feature fully CNC'd intake ports, combustion chambers and exhaust ports for improved air-flow. Dyno tests proved this head is capable of 457 hp & 438 ft-lbs. of torque. High-quality conical beehive springs are secured with steel retainers and valve locks for performance up to .600" valve lift. Match with any one of Edelbrock's LS series intake manifolds and camshafts for a dyno-proven performance combination. Rocker bolt kit #8597 includes 8 rocker bolts that are shorter than stock to prevent the bolts from protruding into the intake ports.

  • CNC Ported to achieve optimal air flow
  • For maximum horsepower and torque
  • For high performance street/light duty racing
DETAILS
Camshaft Type:
Hydraulic Roller
Car/Engine:
Chevrolet LS
Chamber Volume:
65cc
Engine Notes:
Gen III&IV LS1/LS2
Exhaust Port Location:
Standard
HP Range:
400-500
Max. Lift:
0.680''
Port Volume Intake / Exh:
215cc / 76cc
Serie:
E-CNC
Valve Sizes Intake / Exh:
2.02'' / 1.57''
Valve Spring Diameter:
1.30''
Available downloads:
Download instructions

0 of 0 reviews

Average rating of 0 out of 5 stars

Leave a review!

Share your experiences with other customers.


  • - For use in Racing applications only

Edelbrock 79949 - Cylinder Head, Chevrolet LS1/LS2 Gen III&IV, E-CNC 215, 65cc, Hydraulic Roller

The Edelbrock 79949 E-CNC Small Block Chevy GEN 3 & 4 LS cylinder head are designed for 1997 & later GEN 3 & 4 LS1/LS2 Chevy engines including 4.8L, 5.3L, 5.7L & 6.0L. The E-CNC Cylinder Head feature fully CNC'd intake ports, combustion chambers and exhaust ports for improved air-flow. Dyno tests proved this head is capable of 457 hp & 438 ft-lbs. of torque. High-quality conical beehive springs are secured with steel retainers and valve locks for performance up to .600" valve lift. Match with any one of Edelbrock's LS series intake manifolds and camshafts for a dyno-proven performance combination. Rocker bolt kit #8597 includes 8 rocker bolts that are shorter than stock to prevent the bolts from protruding into the intake ports.

  • CNC Ported to achieve optimal air flow
  • For maximum horsepower and torque
  • For high performance street/light duty racing
DETAILS
Camshaft Type:
Hydraulic Roller
Car/Engine:
Chevrolet LS
Chamber Volume:
65cc
Engine Notes:
Gen III&IV LS1/LS2
Exhaust Port Location:
Standard
HP Range:
400-500
Max. Lift:
0.680''
Port Volume Intake / Exh:
215cc / 76cc
Serie:
E-CNC
Valve Sizes Intake / Exh:
2.02'' / 1.57''
Valve Spring Diameter:
1.30''

Available downloads:
Download instructions

0 of 0 reviews

Average rating of 0 out of 5 stars

Leave a review!

Share your experiences with other customers.


- For use in Racing applications only

Accessory Items

Skip product gallery
Head Gasket, Chevrolet Gen IV LS2 6.0L/6.2L

Edelbrock

Part number: 7387

€141.50 incl. vat
Head Gasket, Chevrolet Gen III LS1 5.7L
